Model |
PW-401CMS+H, PW-401CAS+H, PW-401C+H |
PW-501CMS+H, PW-501CAS+H, PW-501C+H |
PW-601CMS+H, PW-601CAS+H, PW-601C+H |
PW-801CMS+H, PW-801CAS+H, PW-801C+H |
PW-1001CMS+H, PW-1001CAS+H, PW-1001C+H |
H.F. Out-put Power |
4 KW |
5 KW |
6 KW |
8 KW |
10 KW |
Oscillation Frequency |
40.68MHZ |
27.12 MHZ |
27.12 MHZ |
27.12 MHZ |
27.12MHZ |
Power Supply |
AC 220/380/400/ 415/440V 3Dia. Voltage to be arranged at instruction |
AC 220/380/400/ 415/440V 3Dia. Voltage to be arranged at instruction |
AC 220/380/400/ 415/440V 3Dia. Voltage to be arranged at instruction |
AC 220/380/400/ 415/440V 3Dia. Voltage to be arranged at instruction |
AC 220/380/400/ 415/440V 3Dia. Voltage to be arranged at instruction |
Input Power |
6.5KVA |
8.5KVA |
10KVA |
15KVA |
18 KVA |
Oscillation Tube |
E3062 |
7T85RB |
7T69RB |
7T69RB |
E3069 |
Rectifier |
Silicon Rectifier |
Silicon Rectifier |
Silicon Rectifier |
Silicon Rectifier |
Silicon Rectifier |
Arc Suppressor |
Highly Sensitive Sparklet Preventor |
Highly Sensitive Sparklet Preventor |
Highly Sensitive Sparklet Preventor |
Highly Sensitive Sparklet Preventor |
Highly Sensitive Sparklet Preventor |
Upper Plate (mm) |
250 x 350 |
300 x 450 |
500 x 600 |
550 x 650 |
550 x 650 |
Lower Plate (mm) |
300 x 400 |
300 x 500 |
600 x 700 |
600 x 700 |
600 x 700 |
Press Stroke (mm) |
150mm |
150mm |
150mm |
150mm |
150mm |
Slide Table Type |
CMS: Manual CAS: Automatic C: No Slide board |
CMS: Manual CAS: Automatic C: No Slide board |
CMS: Manual CAS: Automatic C: No Slide board |
CMS: Manual CAS: Automatic C: No Slide board |
CMS: Manual CAS: Automatic C: No Slide board |
Welding Head Operation |
Pneumatic |
Pneumatic |
Pneumatic |
Pneumatic |
Pneumatic |
